All trucks equipped with a factory weight scale system will require a 105118 Weight Scale Relocation Kit. This kit includes the radius arm brackets for OEM and S&B arms as well as a new rod system that is fully adjustable depending on lift height. We also include brackets in this kit for deleting the weight scale system if you don’t like the look and want to manually adjust your headlights.
Lift Blocks - 101162/101164 (Optional)
We offer 7/8" and 1-7/8" Billet Steel 2.5 Degree lift blocks. Please choose the S&B block height based on how much you want to lift the rear of your truck. Our billet steel lift blocks are designed to fit underneath your factory block and include the 2.5 degree angle needed to correct pinion angle on F450 trucks. These blocks are ridiculously strong and overbuilt even for the F450 application.
U-Bolts (Optional)
U-Bolt length will depend on lift block selection. Please measure your factory U-Bolts and factory lift block to determine the correct U-Bolt length. Do not order without measuring beforehand. We have detailed instructions in the video that explain exactly how to measure and correctly choose the right U-Bolts. All of our longer U-Bolts are 3/4" thread and will require drilling the bottom plate out slightly. We offer the drill bit needed as part number 101384.
